One touch, total control.
TI801 · Single Smart Glass Touch Switch
A single elegant touch zone for one light or one roller shutter.
Glass finish, flawless touch.
The TI801 front panel is high-resistance tempered safety glass with a single backlit capacitive touch zone. Its sensing — built on a humidity-compensated capacitive controller with dynamic auto-calibration — stays precise even on damp surfaces and in difficult conditions.
- Tempered safety glass panel — available in white, black and livid
- Backlit RGB touch indicator — 16 colours and 5 brightness levels
- Humidity-compensated capacitive sensing with auto-calibration
- Service Mode locks the touch keys for safe cleaning
One light or shutter, fully connected.
The TI801 drives a single light or roller shutter and connects over WiFi 6 (2.4 GHz) with Bluetooth LE pairing. Control it from the TCA app anywhere, build schedules, and use Google Home voice commands.
Automatic shutter calibration learns precise open and close travel times, while built-in voltage and current measurement reports live power consumption to the app.
Two-way (va-et-vient) control is smart and fully wireless: pair two switches to the same light or shutter directly in the TCA app — no traveler wires, no rewiring. Commands stay in sync locally, even if WiFi drops.
Technical Specifications
Control & Build
- Touch zones1
- PanelTempered safety glass
- ColoursWhite, black, livid
- Drives1 light or 1 shutter
Electrical
- Outputs2 x 10 A, 250V AC
- RelaysPanasonic
- Power input250V AC
- Consumption300 mA max (3 mA standby)
Connectivity
- WirelessWiFi 6 (2.4 GHz) + Bluetooth LE
- VoiceGoogle Home
- CloudSSL/TLS encrypted
Physical
- Dimensions126 x 92 x 7 mm
- Weight0.2 kg
- Ingress ratingIP40
- Operating temp.-10°C to 50°C
- Warranty36 months
Manuals & Software
Download the latest documentation and tools for the TI801.
