Command every light.
TI803 · Triple Smart Glass Touch Switch
Three independent touch zones for full-room lighting and shutter control.
Command the whole room.
Three independent backlit capacitive touch zones sit on one premium tempered-glass panel. Humidity-compensated sensing with dynamic auto-calibration keeps the TI803 precise even in demanding conditions.
- Tempered safety glass panel — available in white, black and livid
- Three backlit RGB touch zones — 16 colours and 5 brightness levels
- Humidity-compensated capacitive sensing with auto-calibration
- Service Mode locks the touch keys for safe cleaning
Three circuits, endless scenes.
Control three lights, or two lights and a roller shutter, and orchestrate them into scenes through the TCA app over WiFi 6 — with schedules and Google Home voice control.
Automatic shutter calibration and live power monitoring come standard.
Two-way (va-et-vient) control is smart and fully wireless: pair two switches to the same light or shutter directly in the TCA app — no traveler wires, no rewiring. Commands stay in sync locally, even if WiFi drops.
Technical Specifications
Control & Build
- Touch zones3
- PanelTempered safety glass
- ColoursWhite, black, livid
- DrivesUp to 3 lights or shutters
Electrical
- Outputs4 x 10 A, 250V AC
- RelaysPanasonic
- Power input250V AC
- Consumption300 mA max (3 mA standby)
Connectivity
- WirelessWiFi 6 (2.4 GHz) + Bluetooth LE
- VoiceGoogle Home
- CloudSSL/TLS encrypted
Physical
- Dimensions126 x 92 x 7 mm
- Weight0.2 kg
- Ingress ratingIP40
- Operating temp.-10°C to 50°C
- Warranty36 months
Manuals & Software
Download the latest documentation and tools for the TI803.
Interested in the TI803?
Contact our sales team for a tailored quote, or buy the TI803 directly from one of our partner stores below.
Contact Sales
