Two zones, one panel.
TI802 · Dual Smart Glass Touch Switch
Two independent touch zones for flexible light and shutter control.
Two zones on one clean panel.
The TI802 brings two independent backlit capacitive touch zones to a single tempered-glass panel — a refined replacement for cluttered double switches. Humidity-compensated sensing keeps every tap accurate, day or night.
- Tempered safety glass panel — available in white, black and livid
- Two backlit RGB touch zones — 16 colours and 5 brightness levels
- Humidity-compensated capacitive sensing with auto-calibration
- Service Mode locks the touch keys for safe cleaning
Flexible control for lights and shutters.
Drive two lights, one light and one roller shutter, or two shutters — then manage them all from the TCA app over WiFi 6 with schedules, scenes and Google Home voice control.
Automatic shutter calibration and live power monitoring are built in, so the TI802 adapts to almost any room.
Two-way (va-et-vient) control is smart and fully wireless: pair two switches to the same light or shutter directly in the TCA app — no traveler wires, no rewiring. Commands stay in sync locally, even if WiFi drops.
Technical Specifications
Control & Build
- Touch zones2
- PanelTempered safety glass
- ColoursWhite, black, livid
- DrivesUp to 2 lights or shutters
Electrical
- Outputs4 x 10 A, 250V AC
- RelaysPanasonic
- Power input250V AC
- Consumption300 mA max (3 mA standby)
Connectivity
- WirelessWiFi 6 (2.4 GHz) + Bluetooth LE
- VoiceGoogle Home
- CloudSSL/TLS encrypted
Physical
- Dimensions126 x 92 x 7 mm
- Weight0.2 kg
- Ingress ratingIP40
- Operating temp.-10°C to 50°C
- Warranty36 months
Manuals & Software
Download the latest documentation and tools for the TI802.
